System Parameters
- Operating System: Linux
- ROM: 4 GB
- RAM: 1 GB
- CPU: Embedded Processor
Display Parameters
- Screen Size: 4.3-inch
- Operation Method: Touch screen
- Type: Colorful IPS
- Resolution: 800 × 480
- Brightness: 425 cd/m²
Video Parameters
- Supplement Light: Low illumination, IR supplement lights
- Video Standard:
Main stream and sub stream: H.264
Third stream: H.265
- Lens: 2
- FOV: Horizontal: 88°, Vertical: 44°
- WDR: Support
- Resolution: 2×2 MP
Audio Parameters
- Audio Compression Standard: G.711 U, G.711 A
- Audio Input
Built-in omnidirectional microphone
- Audio Output: Built-in loudspeaker
- Audio Compression Bitrate: 64 Kbps
- Audio Quality: Noise suppression and echo cancellation
- Volume Adjustment: Adjustable
Capacity
- Fingerprint Capacity: /
- User Capacity: 20000(Up to 20000 contacts can be added to the device)
- Card Capacity: 100000
- Face Capacity: 10000
- Linked Indoor Station Capacity: 500
- Event Capacity: /
- Sub Door Station Capacity: 16
Network Parameters
- Communication Protocol: TCP/IP, RTSP
- Wired Network: 10/100 Mbps self-adaptive Ethernet
- Wi-Fi: Wi-Fi 802.11 b/g/n
- Bluetooth: Reserved
- 3G/4G/
Authentication
- Card Reading Frequency: 13.56 MHz
- Face Recognition Distance: 0.3 to 2 m
- Face Recognition Accuracy Rate: ≥ 99%
- Face Recognition Duration< 0.2 s per person
Device Interfaces
- Alarm Input: 4 (2 exit butttons and 2 door contacts by default)
- Network Interface: 1 RJ45
- TAMPER: 1
- Exit Button: 2
- RS-485: 1
- USB: /
- Wiegand: /
- TF Card: Reserved
- Lock Control: 2 relay
- Door Contact Input: 2
- Power Interface: 1, 12 VDC input
General
- Button: 1
- Installation: Surface mounting
- Indicator: 0
- Weigh: t0.490 kg
- Protective Level: IP65 & IK08
- Working Temperature: -40° C to 60° C (-40° F to 140° F)
- Working Humidity: 10% to 90%
- Dimensions: 181.93 mm × 84.78 mm × 25.63 mm
- Battery: /
- Power Supply: 12 VDC, 1.5 A
- Application Environment: Outdoor
- Power Consumption: ≤ 6 W
- Language: English,French,BrazilianPortuguese,Spanish,Russian,German,Italian,Polish,Turkish,Vietnamese,Arabic,Czech,Hungarian,Dutch,Romanian,Bulgarian,Ukrainian,Croatian,Serbian,Greek
